Overview
It is an industrial gigabit Ethernet fiber optical transmission equipment which can convert between network
cable and optical fiber cable. It supports 10/100/1000Mbps network bandwidth. It can be used in pairs and
can also be used together with other equipments. It is widely used in surveillance, home network fiber,
etc.
Features
- Provide 1*gigabit fiber optical port and 1*gigabit Ethernet port which can convert between
10/100/1000BASE-T and 1000BASE-X. - Apply to SFP optical module, support hot plug and SFP optical module with different performances.
- Compatibility with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab/z, and Ethernet standard of 10/100/1000Base-T and 1000Base-X.
- Support 10/100/1000Mbps full/half duplex automatic adaptation and automatic MDI/MDIX.
- Support 6kV surge protection,6kV/8kV ESD protection.
- Support -40℃~75℃ working temperature
>
